Isothermal panels

GS112-CS3

Sandwich panels with tongue and groove joint and polyurethane sealing gasket, produced in compliance with European regulation EN 14509, appropriate for the realization of cold rooms at both positive and negative temperatures. The panels are created to provide high thermal isolation performance, as well as mechanical strength, a pleasing appearance, hygiene and easy assembly.

Available in 3 models:

GS 112 Cs3_N: Micro-ribbing on two sides
GS 112 Cs3_C: Semi-smooth (with coplanar joint)
GS 112 Cs3_L: Smooth on two sides

Highlights

Incastro-doppio

Double coupling

Certificazione-GS-Cs3,d0

Reacrion to fire: Euroclass C s3 d0 according to EN 13501-1, obtained through PUR foam insulation with flame retardants

Marcatura-CE

Labelling CE in compliance with EN regulation 14509

Caratteristiche

Module	Useful width = mm 1120
Dimensions	Length: minimum mm 2000, maximum mm 16000
Thicknesses mm	150, 180, 200, 240
Insulation	Rigid polyurethane foam (PUR), density 40 Kg/m³ ± 10%. Initial thermal conductivity λ = 0.021 W/m K, CFC and HCFC-free, range of application -40°C ÷ 60°C

Floors and load capacities

P 100 STANDARD

Floor surface in Galvanized Sheet Steel and Plastic,color grey, nonslip finish, R9 DIN 51130-04

P 100 IX

Floor surface in Stainless sheet steel AISI 304, non-slip finish R12 DIN 51130-04

P 250 F

Floor surface in HPL laminated phenolic plywood, brown color, non-slip finish R10 DIN 51130-04

P 400 FR

Floor surface in HPL laminated phenolic plywood, brown color, non-slip finish R10 DIN 51130-04, supported by internal structure integrated into the foam

P 350 IX

Floor surface in Aisi 304 stainless steel sheet, small R11 DIN 51130-04 non-slip rice grain relief pattern with load distribution plate

P 400 IXR

Floor surface in Aisi 304 stainless steel with R11 DIN 51130-04 non-slip rice grain relief pattern, with a load distribution plate supported by an internal structure integrated into the foam

P 230

R10 floor surface in grain relief aluminium sheets, on Multi System standard floor.

P 300 B

Floor consisting of two overlapping layers, comprising: GS 112 sandwich type insulating panel at the base, with overlapping striated steel plate

P 300 IXB

Floor surface in grain relief AISI 304 stainless steel sheets, applied on Big Panels (vertical type).

P 350 IXB

Floor consisting of three overlapping layers, comprising: insulating sandwich panel at the base, load distribution plate and micro grain relief steel plate

P 400

Floor surface in striated galvanized steel sheets, applied on Multi System standard floor.

P 400 B

Floor consisting of three overlapping layers, comprising: insulating sandwich panel at the base, load distribution plate and a striated steel plate.

P 400 IX

Floor surface in grain relief AISI 304 stainless steel sheets, applied on Multi System standard.

P 400 IXB

Floor consisting of three overlapping layers, comprising: insulating sandwich panel at the base, load distribution plate and a micro grain relief stainless steel plate.

P 550

Floor consisting of two overlapping layers, comprising: Multi System floor panel super reinforced with chipboard sheet and support structure built into the polyurethane foam. Surface in hot dip galvanized steel sheet.

P 550 IX

Floor consisting of two overlapping layers, comprising: Multi System floor panel super reinforced with load distribution plate and support structure built into the polyurethane foam. Surface in grain relief stainless steel sheet.

Available finishes

Prepainted steel sheet

Sendzimir hot-dip galvanised S 250 GD steel plate, pre-painted with 25 µ polyester paint, Ral 9010 white.

Plasticised sheet metal (option)

Sendzimir hot-dip galvanised S 250 GD steel plate, plasticised with 110 µ PVC film, applied hot, Ral 9010 white.

Prepainted and laminated sheet metal (option)

Sendzimir hot-dip galvanised S 250 GD steel plate, pre-painted and laminated with PET film, Ral 9010 white, total covering 45 µ.

Stainless steel sheet (option)

Stainless steel panel, EN 1.4301-2B (AISI 304).

Plasticized stainless steel sheet (option)

Stainless steel panel EN 1.4301-2B (AISI 304) hot plasticised with 110 µ PVC film, Ral 9010 white.

Lamiera inox preverniciata (option)

Stainless steel panel EN 1.4301-2B (AISI 304) pre-painted with 25 µ polyester paint, Ral 9010 white.
